Introduksjon
Thank you for choosing the HOOBRO WH67WJ01 3-Drawer Mobile File Cabinet. This manual provides detailed instructions for assembly, operation, maintenance, and troubleshooting to ensure safe and efficient use of your new cabinet. Please read all instructions carefully before beginning assembly and retain this manual for future reference.
Image: The HOOBRO WH67WJ01 3-Drawer Mobile File Cabinet positioned under an office desk, showcasing its compact design and farmhouse aesthetic with white drawers and a walnut top.
Sikkerhetsinformasjon
- Always follow the assembly instructions carefully to prevent injury or damage to the product.
- Sørg for at alle skruer og festemidler er godt strammet før bruk. Kontroller regelmessig og stram til etter behov.
- Install locking wheels diagonally to maximize stability and prevent unintended movement.
- Ikke overbelast skuffene. Fordel vekten jevnt for å opprettholde stabiliteten.
- Hold små deler og emballasjematerialer unna barn og kjæledyr under montering.
Pakkeinnhold
Kontroller at alle komponenter er til stede før monteringen starter. Hvis noen deler mangler eller er skadet, vennligst kontakt kundestøtte.
- 1 x HOOBRO WH67WJ01 File Cabinet on Wheels
- 1 x Accessory Kit (includes screws, tools, and other hardware)
- 1 x bruksanvisning
Oppsett og montering
Assembly of the HOOBRO WH67WJ01 file cabinet is designed to be straightforward. Follow the included step-by-step instructions provided in the accessory kit. Ensure you have adequate space and the necessary tools (usually included) before starting.
- Pakk ut komponenter: Ta forsiktig alle delene ut av emballasjen og legg dem på en ren, myk overflate for å unngå riper.
- Identifiser deler: Refer to the parts list in the accessory kit to identify each component.
- Sett sammen ramme: Follow the diagrams to connect the main frame pieces using the provided hardware.
- Installer skuffeskinner: Attach the drawer slides to the cabinet frame and the drawer sides as indicated. Ensure they are correctly oriented for smooth operation.
- Montering av skuffer: Construct each drawer, ensuring all panels are securely fastened.
- Fest håndtak: Fest håndtakene foran på hver skuff.
- Installer hjul: Attach the five smooth-rolling casters to the bottom of the cabinet. Ensure the two lockable casters are installed diagonally for optimal stability when locked.
- Sett inn skuffer: Carefully slide the assembled drawers into their respective slots.
- Sluttsjekk: Kontroller at alle tilkoblinger er stramme og at kabinettet er stabilt.
Image: A diagram illustrating the placement of five casters on the bottom of the cabinet, highlighting two lockable casters for flexible positioning and stability.
Bruksanvisning
Skuffefunksjonalitet
The HOOBRO WH67WJ01 features three drawers designed for various storage needs:
- De to øverste skuffene: These are standard storage drawers suitable for office supplies, small items, or documents.
- Nederste skuff: This drawer is specifically designed for A4 and Letter-size hanging files. It includes an adjustable file rod for flexible organization.
Image: The HOOBRO file cabinet with its drawers open, demonstrating the top two drawers for general storage and the bottom drawer configured for hanging files.
Regulerbar File Stenger
The bottom drawer's file rod can be adjusted to accommodate both A4 and Letter-size documents. To adjust, simply slide the rod to the desired position within the designated slots.
Image: A close-up diagram illustrating how to adjust the file rods in the bottom drawer to fit either A4 or Letter-sized hanging files.
Låsbar skuff
The bottom drawer is equipped with a lock to secure your private files and valuable items. Insert the key into the lock and turn to secure or unlock the drawer. Keep the keys in a safe place.
Note: For enhanced security, ensure the top two drawers are closed when the bottom drawer is locked. Access to the bottom drawer contents may be possible if the second drawer is removed while the bottom drawer is locked.
Bilde: En detaljert view of the lock mechanism and key on the bottom drawer, alongside an easy-pull handle on the top drawer.
Mobilitet
The cabinet is fitted with five smooth-rolling casters for easy movement. Two of these casters are lockable. To move the cabinet, unlock the casters. To keep the cabinet stationary, engage the locks on the two designated casters.
Vedlikehold
- Rengjøring: Tørk av skapets overflater med en myk klutamp klut. Unngå å bruke sterke kjemikalier eller slipende rengjøringsmidler, da disse kan skade overflaten.
- Skuffelys: The high-quality slide rails are designed for smooth operation. If a drawer becomes stiff, ensure it is not overloaded and check for any obstructions. Lubrication is generally not required.
- Maskinvare: Sjekk alle skruer og festemidler med jevne mellomrom for å sikre at de sitter godt fast. Stram til etter behov for å opprettholde den strukturelle integriteten.
- Hjul: Keep casters free of debris to ensure smooth rolling. If a caster becomes difficult to move, clean any accumulated dust or hair from the wheel mechanism.
Bilde: Et nærbilde view of the high-quality slide rails on a drawer, designed for smooth and quiet operation.
Feilsøking
| Problem | Mulig årsak | Løsning |
|---|---|---|
| Skuffen lukkes ikke jevnt. | Overloaded drawer, obstruction in slide, loose hardware. | Reduce drawer contents. Check for and remove any obstructions. Ensure all screws on drawer slides are tight. |
| Bunn file drawer does not close with fileer inne. | File rod incorrectly positioned, oversized file mapper. | Ensure the adjustable file rod is correctly set for A4 or Letter size. Verify that file folders are standard size and not protruding. |
| Skapet er ustabilt eller vingler. | Loose hardware, casters not locked. | Check and tighten all assembly screws. Ensure the two lockable casters are engaged when the cabinet is stationary. |
| Hjulene ruller ikke fritt. | Debris in wheels, casters locked. | Clean any hair or debris from the caster wheels. Ensure casters are unlocked for movement. |
Spesifikasjoner
Image: A detailed diagram showing the dimensions of the HOOBRO WH67WJ01 file cabinet, including overall height, width, depth, and individual drawer measurements.
| Trekk | Detalj |
|---|---|
| Modellnummer | WH67WJ01 |
| Merke | HOOBRO |
| Produktdimensjoner | 40 cm D x 40 cm B x 66 cm H (15.7 cm D x 15.7 cm B x 26 cm H) |
| Materiale | Konstruert tre, metall |
| Farge | White + Walnut |
| Antall skuffer | 3 |
| Lås type | Key (for bottom drawer) |
| Mobilitet | 5 Casters (2 lockable) |
| Anbefalt bruk | Files & Folders, Office Storage, Printer Stand |
| Montering påkrevd | Ja |
| Varevekt | 37 pund (16.8 kg) |
Garanti og støtte
For warranty information, missing parts, or technical support, please refer to the contact details provided with your purchase documentation or visit the official HOOBRO website. Please have your model number (WH67WJ01) and purchase date ready when contacting support.
