1. Introduksjon
This manual provides essential information for the safe and efficient operation of your ULTIMEA Poseidon M20 Pro U2203 2.1ch Sound Bar. Please read it thoroughly before using the product and retain it for future reference.
The ULTIMEA Poseidon M20 Pro U2203 is an all-in-one 2.1 channel sound bar designed to enhance your audio experience for TV, gaming, and music. It features a built-in subwoofer, app control, and multiple connectivity options.
2. Nøkkelfunksjoner
- Alt-i-ett-design: Built-in dual speakers, a 3-inch subwoofer, and side-firing bass ports deliver deeper lows and expand surround effects. The 2.1ch sound offers a superior audio experience for movies, music, or games.
- Compact Size with Enhanced Bass: ULTIMEA's exclusive BassMX technology enhances low frequencies with adjustable bass. The compact design allows for versatile placement on a stand, cabinet, under the TV, or wall-mounted.
- ULTIMEA Smart App Control: Control your sound bar with the ULTIMEA smart app, allowing you to switch multiple EQ modes, adjust bands, and matrix settings. Regular OTA updates ensure optimized performance.
- 121 Preset EQ Matrices: The ULTIMEA App provides 121 preset equalizer matrices, tailored for four distinct sonic preferences: Bass, Pop, Classical, and Rock. Precise tuning and dynamic adjustments enable a finely-tuned listening experience.
- 10-Band Equalizer Settings: Enhance your audio with 6 tailored EQ modes: Movie, Music, Voice, Sport, Game, and Night. Use the ULTIMEA App's "Customize" feature for fine-tuning to match personal taste and environment.
- Multi Connections: Supports optical, AUX, Bluetooth 5.4, and USB inputs for universal compatibility. Bluetooth 5.4 ensures fast, stable wireless streaming. An additional "SUB OUT" port allows connection of an active subwoofer for enhanced bass.
3. Hva er i esken
Please check that all components are present upon unpacking:
- 1 x ULTIMEA Poseidon M20 Pro U2203 Sound Bar
- 1 x fjernkontroll (batterier ikke inkludert)
- 1 x brukerhåndbok
- 1 x Power Adaptor for Soundbar (2m)
- 1 x Stereo 3.5mm to 3.5mm Audio Cable (1.5m AUX Cable)
- 1 x Digital Optical Cable (1.5m)
- 4 x Veggmonteringssett
- 2 x veggbrakett
- 2 x Mounting Screw on Speakers
4. Produktet er overview
4.1 Kontroller og indikatorer
The sound bar features intuitive controls for easy operation.
Image: Top panel controls of the ULTIMEA Poseidon M20 Pro U2203 soundbar.
4.2 Tilkoblinger på bakpanelet
The rear panel provides various ports for connecting to your audio sources.
Image: Rear panel connections of the ULTIMEA Poseidon M20 Pro U2203 soundbar.
- DC IN: Strøminngangsport.
- AUX: 3.5mm audio input for analog devices.
- OPTISK: Optical audio input for digital audio sources.
- USB: USB input for media playback (supports MP3 files with 128GB max memory).
- SUB UT: Output port for connecting an external active subwoofer.
5. Oppsett
5.1 Slå på
- Koble strømadapteren til DC IN porten på baksiden av lydplanken.
- Koble den andre enden av strømadapteren til en stikkontakt.
- Press the power button on the sound bar or remote control to turn it on.
5.2 Plasseringsalternativer
The sound bar can be placed on a TV stand or wall-mounted.
Image: Flexible placement options for the soundbar.
5.3 Koble til TV-en
Choose one of the following connection methods based on your TV's available ports:
5.3.1 Optisk tilkobling
- Koble den ene enden av den digitale optiske kabelen til OPTISK port på lydplanken.
- Connect the other end of the Digital Optical Cable to the Optical Digital Audio Out port on your TV.
- On your TV's audio settings, select "Optical" as the audio output and set the digital sound out format to "PCM" or "Passthrough".
Image: Optical connection diagram.
5.3.2 AUX-tilkobling
- Koble den ene enden av 3.5 mm lydkabelen til AUX port på lydplanken.
- Connect the other end of the 3.5mm Audio Cable to the 3.5mm Audio Out (Headphone) port on your TV.
- On your TV's audio settings, select "Headset" or "External Speaker" as the audio output.
Image: AUX connection diagram.
5.3.3 Bluetooth-tilkobling
- Trykk på BT button on the remote or the sound bar to switch to Bluetooth mode. The LED indicator will flash.
- Aktiver Bluetooth på smarttelefonen eller annen enhet.
- Select "Poseidon M20 Pro" from the list of available Bluetooth devices to pair. The LED indicator will turn solid blue once connected.
Bilde: Bluetooth-tilkoblingsdiagram.
6. Betjening av lydplanken
6.1 Grunnleggende funksjoner
- Slå på/av: Short press the power button to turn on, long press for 2 seconds to turn off.
- Volumkontroll: Use the '+' and '-' buttons on the sound bar or remote to adjust volume.
- Valg av inngangsmodus: Short press the power button (after turning on) or use the dedicated buttons on the remote (OPT, AUX, BT) to switch between input modes.
6.2 EQ Modes and Customization
The ULTIMEA Poseidon M20 Pro U2203 offers various EQ modes and customization options via the remote control and the ULTIMEA Smart App.
6.2.1 Preset EQ Modes
Select from 6 tailored EQ modes for different content:
- Film: Optimized for cinematic sound.
- Musikk: Enhanced for musical playback.
- Stemme: Improves dialogue clarity.
- Sport: Suitable for sports broadcasts.
- Spill: Gir altoppslukende spillyd.
- Natt: Reduserer dynamisk område for lytting sent på kvelden.
6.2.2 ULTIMEA Smart App Customization
For advanced control, download the ULTIMEA Smart App:
- 121 Preset EQ Matrices: Choose from matrices tailored for Bass, Pop, Classical, and Rock.
- 10-bånds equalizer: Fine-tune Bass, Midrange, and Treble frequencies to your preference.
Image: ULTIMEA App showing 121 preset EQ matrices.
Image: ULTIMEA App showing 10-band equalizer settings.
7. Vedlikehold
- Rengjøring: Use a soft, dry cloth to clean the surface of the sound bar. Do not use liquid cleaners or aerosols.
- Lagring: If not in use for an extended period, unplug the sound bar from the power outlet and store it in a cool, dry place.
- Unngå fuktighet: Keep the sound bar away from water, moisture, and direct sunlight.
8. Feilsøking
| Problem | Mulig årsak | Løsning |
|---|---|---|
| Ingen strøm | Power cord not connected or outlet not working. | Ensure power cord is securely connected and try a different outlet. |
| Ingen lyd | Incorrect input mode selected or TV audio settings incorrect. | Select the correct input mode (Optical, AUX, BT) on the sound bar. Check TV audio output settings (e.g., set to PCM for Optical). |
| Bluetooth-tilkobling mislykkes | Sound bar not in pairing mode or device too far. | Ensure sound bar is in Bluetooth mode (LED flashing). Move device closer to the sound bar. Forget device on your phone and re-pair. |
| Lydforvrengning | Volumet er for høyt, eller lydkildens kvalitet er lav. | Reduser volumet. Prøv en annen lydkilde eller kabel. |
9. Spesifikasjoner
- Modellnavn: Poseidon M20 Pro
- Varemodellnummer: U2203
- Høyttalertype: Soundbar
- Høyttaler Maksimal utgangseffekt: 132 watt (toppeffekt)
- Frekvensrespons: 70 Hz
- Monteringstype: Tabletop Mount / Wall Mount
- Produktdimensjoner: 10.8 D x 40 B x 7 H centimeter
- Varevekt: 2.24 kg
- Tilkobling: Bluetooth 5.4, Optical, AUX, USB
- Spesielle funksjoner: All-in-one Design, ULTIMEA Smart App Control, 10 Band Equalizer Settings, 121 Preset Equalizer Matrices, Adjustable Bass & Midrange & Treble, BassMX Technology, Built-in Subwoofer
- Produsent: ULTIMAT
- Opprinnelsesland: Kina
10. Garanti og støtte
For warranty information, technical support, or customer service inquiries, please refer to the warranty card included with your product or visit the official ULTIMEA webnettstedet. Ta vare på kjøpskvitteringen som kjøpsbevis.
